SDPS-reconstruction of the "City in Spain" scene
:
Initial stereo images 1028 × 1028
Area of reconstruction 544 × 960
Epipolar lines' range: [32, 991]
Pixels' range: [448, 991] in the left image and [112, 655] in the right image
Range of
x
-parallaxes (disparities): [0, 20]
Weight of occluded points: 100
Relative adaptation of grey level differences: [0.4, 1.6]
DPM smoothing by 7 × 7 median filtering
Pentagon
Left stereo image
Right stereo image
Range image (DPM)
Ortho image (DPM)
